Product Overview Product Features Product Specs

ZY-NL (C1) is a dual band Wi Fi 6 vertical 5G mobile router. The series is equipped with 5G chips designed specifically for IoT/eMBB applications, implemented through soft routing, and automatically adapts to 5G NR NSA and SA dual-mode networking, supporting TDD and FDD. The product has a built-in antenna and the advantage of Wi Fi 6 technology. Wi Fi supports IEEE 802.11 a/b/g/n/ac/(ax300) protocol. Supports 1 LAN port. Support custom switching of 3 SIM cards, including 2 built-in patch SIM cards, to achieve data overlay and operator selection. Widely used in industries such as enterprise office, smart education, smart energy, smart cities, remote healthcare, high-definition video, and home entertainment

5G Gigabit wireless broadband, instantly activated with card insertion. Download speed up to 2Gbps and upload speed up to 500Mbps.
Full mode and full network, one-stop support for 5G

Supports 5G SA/NSA dual-mode networks, fully compatible with 3G/4G/5G, reduces deployment costs, one-stop support.
Free placement, unrestricted

Supports wireless cellular network broadband access, freeing itself from wired constraints such as network cables, telephone lines, and fiber optics, making deployment more flexible and efficient.
Vertical design, towering

Pure white color scheme, curved vertical, wind tunnel type heat dissipation system. Easy integration into home scenes, more in line with existing popular home decoration styles, and also more in line with the aesthetic preferences of modern young people.
Dual band Wi Fi 6, faster, more powerful

Supports 1024QAM modulation technology, increases data capacity by 50%, and data transmission is faster, more powerful.
.
High gain built-in antenna

8 omnidirectional high gain built-in antennas provide stronger signals and longer coverage.

type	project	describe
platform	CPU	Zhanrui UDX710
platform	system	Linux
Memory	RAM Random Access Memory	4GB
Memory	ROM Read Only Memory	2GB
radio frequency	3GPP	R8,R9...,R15
	maximize throughout	HSDPA 2G MAX maximum 42.2Mbps (download) (Category 24) HSUPA MAX Maximum 11Mbps (Upload) (Category 7) WCDMA 3G MAX maximum 384Kbps (download)/384Kbps (upload) LTE FDD 4G China Unicom MAX maximum 300Mbps (download)/50Mbps (upload) LTE TDD MAX 4G Mobile Maximum 260Mbps (Download)/30Mbps (Upload) 5G NR TDD MAX maximum 2Gbps (download)/500Mbps (upload)
	WCDMA/HPSA 3G frequency band	Band1
	TDD-LTE Mobile 4G Frequency Band	B34/B38/B39/B40/B41
	FDD-LTE Telecom/Unicom 4G frequency band	B1/B3/B5/B8/
	5G NR frequency band	FDD:N1/N3/N28 TDD:N41/N78
	output power	Class 3 (24 dBm+1/-3 dB), WCDMA frequency band Class 3 (23 dBm ± 2 dB), LTE frequency band Class 3 (23 dBm ± 2 dB), 5G NR frequency band
	ANT RF Circuit	LTE: 1T2R 5G:1T4R
WIFI	WiFi main chip	UMW2651 Spreadtrum+AIC8800DW Aike Micro
	agreement	IEEE 802.11 a/b/g/n/ac（ax300）
	frequency	2.4GHz 5GHz
	Wireless channel	20/40/80MHz
	receiver sensitivity	MCS9: -63dBm@10 % PER MCS7: -68dBm@10 % PER 54M： -70dBm@10 % PER 11M： -83dBm@8 % PER 6M： -88dBm@10 % PER 1M： -90dBm@8 % PER
	Transmission power	18dBm(Max) in 11b mode 16dBm(Max) in 11g mode 15dBm(Max) in 11n mode 15dBm(Max) in 11ax mode
	speed	11ac:867/780/650.....65Mbps (Auto Rate Sensing) 11g:54/48/36/24/18/12/9/6 Mbps (Auto Rate Sensing) 11b:11/5.5/2/1 Mbps (Auto Rate Sensing) 11n:300 Mbps /....../6.5Mbps (Auto Rate Sensing) 200~330 Mbps @ 11ac
Other configurations	key	Power switch, reset button
	USB interface	Type-c
	SIM card slot	Plug in card x 1, SMT card ESIM x 2 (optional)
	power supply	DC 12V
	RJ45	1*LAN
	pilot lamp	Power/WiFi (green light), 4G/5G (tri color light)
application	support agreement	TCP/UDP/HTTP/PING/HTTPS/FTPS/MQTT/MMS
	IP4/IP6	support
	WEBGUI	support
	USB network sharing function	support
	FOTA	support
	Encryption method	WEP,WPA/WPA2/WPA3-Personal/WPA3-Enhanced Open, WPS 2.0, WAPI, WPI-SMS4, EAP-TLS/EAP-TTLS/EAP-PEAP/EAP-SIM/EAP-AKA
temperature	Usage temperature	-0~ +40℃
temperature	storage temperature	-20~ +70℃
authentication	CCC	YES
	Radio transmission approval	YES
	Network access	YES
package	power supply	DC 12V 2A
	certificate of conformity	*1
	instructions	*1
